stone carving machine

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1464948

• Place of Origin:

  China
• 1． Features
  Imported linear guideways, double lines and four slippers make this machine have high bearing capability, stable function, high precision and long working life.

  Welding steel structure, the working table use steel plate. Heavy loading up to 1 ton.
  Power of spindle motor is stainonary, and has high effiency
  The software has wonderful compatible, and can be compatible Type3, Artcam,Castmate,Ucancam and many kinds of CAD,CAM software
  The cutting tools have cooling system,which imports the working life of the tools

  2. Application:

  Suitble for cutting or engraving granite, marble, sandstone, glass and so on.

  Model SB-6060
  Working area of X, Y 600*600MM
  Working area of z 100mm
  Max.speed 20000mm/min
  Max.working speed 7000mm/min
  Working delicacy 0.05mm
  Repetition setting accuracy 0.05mm
  Order of engraving G code,uoo,mmg,plt
  Surroundings for softwareWindows 98/2000/xp
  Working voltage AC220V/50HZ
  The power of spindle 2.2kw
  Rotating Spindle Speed0~24000rpm/min
  Working modestepper
